Welcome to Hunter's ADAS Video Hub

In this video, we’ll showcase the features that make the Ultimate ADAS® a true game-changer in the automotive industry. Whether you're aiming to reduce turnaround times or enhance service quality, Hunter Engineering has the tools you need to elevate your shop’s performance.

Tiring of the headaches and anxiety from subletting work that his shop was ultimately responsible for, Jim Smith of Complete Collision Center in St. Robert, MO decided it was time to simply take control of ADAS work. He found that in-house control in alignment, balancing and ADAS equipment from Hunter Engineering.

“We got the whole package,” Smith said; “everything we need to accommodate the things we need to for our customers, and the things we need to properly do an ADAS or alignment procedure.”

Now available for Honda and Acura dealers, Hunter’s new Ultimate ADAS™ system removes much of the guesswork with ADAS calibrations by cutting setup time by up to 70 percent for some procedures.

Innovative gimbal-mounted lasers instantly determine the exact target locations for targets, providing comprehensive around-the-vehicle coverage. The lasers’ precise measurements constantly monitor and confirm placement accuracy, compensating for factors such as non-level floors and removing the need for time-consuming, inexact plumb bobs, string and tape measures.

Juan Bonilla, co-owner RSC Automotive in San Clemente, CA, didn’t hesitate to recognize that wheel alignments lead directly to profitable ADAS work. “We saw the need, because we were not going to be able to successfully complete accurate alignments,” since now the electronics tie into the mechanics, he says. “You can’t do one or the other without resynching the whole system.”

Bonilla originally had space concerns about performing ADAS procedures, but following a Hunter training course, he realized many calibrations could be done with a little creative thinking. RSC selected Hunter equipment to service this growing ADAS work. The impact has been not only in sales – “They’ve gone up,” Bonilla says – but also in being able to “tap into an area we’ve never explored before.” The effects of adding this new area go beyond financial.Bonilla says technicians enjoy the morale boost from doing sophisticated work, customers are impressed, and “We call ourselves a one-stop shop, because we are a one-stop shop.”

Hunter will continue to play a key role in RSC’s planned expansion into the building next door. Bonilla says, “Hunter equipment gives us more confidence and places our name at a higher standard.”

As each month goes by, performing ADAS calibrations becomes less of a choice and more of a market necessity. Step one is gathering accurate information and avoiding misconceptions. With the help of Hunter’s Ultimate ADAS®, Babcox Media’s Kevin Linger discusses a number of important ADAS topics, such as determining adequate shop space, compensating for non-level floors, and appropriate lighting and wall color, providing a solid foundation for helping guide shops to a smooth transition.

Not that long ago, ADAS calibrations were the wave of the future. That wave will still get bigger, but the future is arriving now. Shop owners wanting to ride that wave to greater profitability are in a better position than they may think, since equipment they’re using now – think alignment systems – gets them halfway there. Babcox Media’s Kevin Linger discusses how shops can take advantage of the huge ADAS opportunities through the logical service pairing of alignment and calibrations, widening an existing revenue stream while meeting customer safety needs at the same time.

Preparing to perform ADAS calibrations involves a number of important considerations, such as understanding ADAS functionality, when resets are required, the need for pre- and post-diagnostic scans, space and lighting requirements, and more. To ensure a successful outcome, Hunter’s ADASLink® diagnostic scan tool and the Bosch DAS 3000 static fixture guide techs step-by-step through intricate calibration procedures for more than 25 million vehicles.

Today, alignment inspections and ADAS calibrations go together like pieces of a jigsaw puzzle. Babcox Media’s Andrew Markel and Hunter’s Dave Fox discuss important ADAS considerations once the vehicle is on the rack, including identifying the internal and external locations of ADAS components, calibration procedures, the importance of documentation, and getting increasingly comfortable working with this type of technology.

It’s a common misconception that performing ADAS calibrations requires a massive investment right off the bat. The reality is that the calibrations market can be approached gradually, gaining experience and expertise over time, like any other automotive service. Babcox Media’s Kevin Linger discusses three sequential – but entirely optional – levels of commitment, from dynamic calibrations to static calibrations to the more advanced capabilities provided by Hunter’s Ultimate ADAS®. The vast majority of calibrations can be performed in-house, in a small area of space, by typical technicians, and with affordable equipment.

Opportunity cost is usually framed in terms of giving up B because you’ve chosen A. But what about the opportunity cost of not doing A when you could (and should) be doing A? Babcox Media’s Kevin Linger discusses how subletting ADAS work costs more than it may appear. Your shop not only gives up profitability while retaining liability, but also loses other possible repairs and follow-up services, as well as risks diminishing customer loyalty. The cost of waiting to perform ADAS calibrations is expensive, and it grows every day. When you’re ready to reclaim your rightful revenue, Hunter’s Ultimate ADAS® will be ready to help.

Although a topic of great interest in the automotive industry, it’s sometimes easy to overlook that ADAS was created for the benefit of real-life vehicle owners. The more shop owners and technicians talk to and educate their customers about the necessity of properly maintaining these safety systems, the better for everyone.

Babcox Media’s Kevin Linger examines several approaches for having effective discussions about ADAS with the different types of customers that come into the shop.

Advanced driver assistance systems (ADAS) are an increasingly important development in vehicle safety.

In this video, Hunter Engineering describes the importance of ADAS calibration post-wheel alignment. Advanced driver assistance systems are designed to help keep drivers safe in multiple ways, but a proper alignment is essential for ADAS to work as intended, by ensuring that it coincides with the direction of travel and steering wheel direction.

Many manufacturers require aligning the ADAS electronically when making mechanical alignment adjustments. While a four-wheel alignment is important to perform for its own sake, it’s also key to ensuring that ADAS radar and cameras coincide with the vehicle’s direction of travel to remain fully functional.

Now approved by OEMs Honda and Acura, Hunter’s new Ultimate ADAS® system removes much of the guesswork with ADAS calibrations by cutting setup time by up to 70 percent for some procedures. Innovative gimbal-mounted lasers instantly determine the exact target locations for targets, providing comprehensive around-the-vehicle coverage.

Now approved by OEMs Honda and Acura, Hunter’s new Ultimate ADAS® system removes much of the guesswork with ADAS calibrations by cutting setup time by up to 70 percent for some procedures. Innovative gimbal-mounted lasers instantly determine the exact target locations for targets, providing comprehensive around-the-vehicle coverage.

Hunter product specialist Ryan Gerber shows how to set up for front-facing camera (forward-facing camera) single recognition calibration. The Ultimate ADAS® system’s innovative gimbal-mounted lasers instantly determine the exact target locations for targets, providing comprehensive around-the-vehicle coverage.

Hunter product specialist Ryan Gerber demonstrates setting up for front-facing radar (forward-facing radar) calibration using a traditional corner cube. The Ultimate ADAS® system’s innovative gimbal-mounted lasers instantly determine the exact target locations for targets, providing comprehensive around-the-vehicle coverage.

Hunter product specialist Ryan Gerber walks through the setup for side view camera (otherwise known as Honda LaneWatch) single recognition calibration. The Ultimate ADAS® system’s innovative gimbal-mounted lasers instantly determine the exact target locations for targets, providing comprehensive around-the-vehicle coverage.

Hunter product specialist Ryan Gerber shows how to set up for front-facing camera (forward-facing camera) single recognition calibration. The Ultimate ADAS® system’s innovative gimbal-mounted lasers instantly determine the exact target locations for targets, providing comprehensive around-the-vehicle coverage.

Hunter product specialist Ryan Gerber demonstrates setting up for front-facing radar (forward-facing radar) calibration using a flat plate. The Ultimate ADAS® system’s innovative gimbal-mounted lasers instantly determine the exact target locations for targets, providing comprehensive around-the-vehicle coverage.

Hunter product specialist Ryan Gerber shows how to configure mat placement for surround view camera calibration. The Ultimate ADAS® system’s innovative gimbal-mounted lasers instantly determine the exact target locations for targets, providing comprehensive around-the-vehicle coverage.

Following a basic introduction, Hunter product specialist Ryan Gerber demonstrates several calibration procedures for a 2024 Kia Telluride, including front-facing camera, front-facing radar and surround view camera. Hunter’s Ultimate ADAS® combines standard-defining alignment technology with the fastest and most precise target placement for ADAS calibrations.

Following a basic introduction, Hunter Product Specialist Ryan Gerber demonstrates two front- facing camera calibration procedures for a 2025 Subaru Outback: single recognition, known as Subaru EyeSight, and secondary camera, single recognition, commonly known as Subaru Mono-Wide.

Hunter Field Training Manager Miles Dierker provides a detailed demonstration of ADASLink®s expansive capabilities, including diagnostics, requested procedures, saved reports, reading DTCs, data streams, test menus, service information database, wiring diagrams and much more.

Hunter Alignment Product Manager Alan Hagerty demonstrates the ease with which ADASLink® diagnostic scan tool can perform a required steering system reset following an alignment.

Hunter Alignment Product Manager Alan Hagerty demonstrates how easy it is to take advantage of screen mirroring technology for your Hunter alignment equipment by quickly setting up an account with remote access provider Splashtop.

Hunter ADAS Product Specialist Ryan Gerber demonstrates how the combination of ADASLink® diagnostic scan tool and Hunter’s innovative Ultimate ADAS® system yields an integrated, seamless static front-facing camera calibration for a 2024 Toyota RAV4.

Following a bumper repair on a 2022 Genesis G70, calibrating the front radar was a necessity. But with the fascia already reinstalled, Babcox Media’s Joe Keene explains, retrieving the required lot number from the nearly inaccessible radar unit presents an uncommon challenge. Joe deftly solves it with the aid of a borescope, before setting up the radar stand and proceeding with a successful calibration via step-by-step guidelines from the ADASLink® diagnostic scan tool.

For some ADAS calibrations, the challenges aren’t in the calibrations themselves, but in the details of preparing for them.

As Babcox Media’s Joe Keene shows for this forward-facing camera calibration following a windshield replacement on a Stellantis vehicle, the procedure itself requires little more than driving. But first the technician will need to perform a few necessary tasks, such as ensuring a completed FCA registration.

Additionally, prior to driving the vehicle, the technician must select a route that avoids stopping, which will negate the calibration in progress. Internet access must also be maintained throughout the procedure. As Joe says, “See how you do it before you do it.”

The step-by-step onscreen guidance of ADASLink® ensures no steps are missed, eliminating guesswork and providing a precise and thoroughly documented calibration for more than 25 million vehicles.

This 2017 BMW 750i xDrive provides a great example of how simple static ADAS calibrations can be when using Hunter’s ADASLink® scan tool and the DAS 3000. As Babcox Media’s Joe Keene demonstrates following an alignment, all that’s required is confirming basic setup, following clear, step-by-step directions for target placement, and then standing back and letting ADASLink® do its work.

When it comes to ADAS calibrations, precision isn’t a goal – it’s a requirement. Adaptive cruise control cameras and radar only function properly if they’re pointed in exactly the right direction. Using Hunter’s ADASLink® diagnostic scan tool, Babcox Media’s Joe Keene carefully walks though the steps for calibrating a Honda front radar camera, from a pre-scan for DTCs, to all the steps for properly setting up the stand for aiming, through making the necessary manual adjustments to get within tolerance. ADASLink®’s onscreen guidance ensures no steps are missed, eliminating guesswork and providing a precise and thoroughly documented calibration for more than 25 million vehicles.

A windshield replacement required the removal and replacement of the front-facing camera on this 2021 Audi Q3. As Babcox Media’s Joe Keene expertly demonstrates, the static calibration of the camera proceeds like clockwork with Hunter’s ADASLink® diagnostic scan tool methodically progressing through all the necessary steps, such as the detailed pre-scan, target placement and measuring wheel height.

An ADAS component usually doesn’t have to be damaged to require a calibration. It only has to be repositioned. That’s the case with the front long-range radar on this 2020 GMC Yukon Denali, following the replacement of the front bumper. Babcox Media’s Joe Keene demonstrates the step-by-step instruction provided by Hunter’s ADASLink® diagnostic scan tool, exploring some nuances of a dynamic calibration of the Denali’s adaptive cruise control.

A windshield replacement in the front and bumper damage in the back of this Hyundai Santa Cruz provides a good opportunity for a number of helpful ADAS calibration reminders, says Babcox Media’s Joe Keene. They include making sure your software is the current version; being sure of a mobile Wi-Fi hot spot for the test drive; verifying use of OEM glass; removing ADAS components alone requires calibration; and the importance of first performing an alignment.

ADAS can do quite a bit to improve safety, notes Babcox Media’s Joe Keene, but the driver must still become familiar with how the system works. Failure to do so can result in a collision, as was the case with this Mazda, which in turn results in the need for front radar calibration. The key to this Mazda millimeter-wave radar calibration is precisely establishing the centerline. With the aid of an alignment laser, radar reflector stand and Hunter’s ADASLink® diagnostic scan tool, Joe is able to quickly and accurately complete a successful calibration, and easily access the detailed documentation to prove it.

When a new windshield goes in, a recalibration of the front windshield camera will need to come with it. For this calibration on a Mazda6 Grand Touring, Babcox Media’s Joe Keene notes the increasing use of factory glass, which can reduce the risk of a skewed calibration. As Joe demonstrates, carefully and precisely setting up the targets as directed by Hunter’s ADASLink® diagnostic scan tool is the key to a successful static calibration. ADASLink®’s onscreen guidance ensures no steps are missed, eliminating guesswork and providing a precise and thoroughly documented calibration for more than 25 million vehicles.

Thanks to ADAS, repairing or replacing a windshield isn’t the straightforward task it used to be. Yet the required calibration itself can still be, with the help of Hunter’s ADASLink® diagnostic scan tool and the DAS 3000. Babcox Media’s Joe Keene demonstrates how to calibrate the front-facing camera on a 2020 Honda Civic. ADASLink's® detailed onscreen guidance eliminates guesswork and ensures a precise and documented calibration.

Learn how quick and easy it is to perform an ICC front-distance milliwave radar sensor calibration on a 2020 Nissan Pathfinder with the Hunter ADASLink® diagnostic scan tool and Bosch DAS 3000 static fixture. The detailed onscreen guidance of ADASLink® combined with the streamlined processes of the DAS 3000 eliminates guesswork and ensures a precise and thoroughly documented calibration for more than 25 million vehicles.

Sometimes a calibration isn’t a calibration until the vehicle knows about it. As Babcox Media’s Joe Keene demonstrates, merely reprogramming or replacing a particular ADAS component isn’t always enough. In this example, a windshield repair on a Ford F-150, the vehicle needs to be “told” that the front-facing camera is coming off, its data is being saved and reloaded, and then going back on. Techs may not be aware of these extra steps. Skipping them could mean additional diagnostic procedures will be needed, costing unexpected time and money. These procedures are necessary for all Ford vehicles. The step-by-step onscreen guidance of ADASLink® ensures such extra procedures are performed, eliminating guesswork and providing a precise and thoroughly documented calibration for more than 25 million vehicles.

As with any ADAS calibration, notes Babcox Media’s Joe Keene, Hunter’s ADASLink® diagnostic scan tool will lead the technician easily and logically through setting up and calibrating the surround view system for a 2020 Ford F-150. A static fixture isn’t necessary for this alignment procedure, because mats, a tape measure and a little tape are all that’s needed. Joe demonstrates the need for accurately measuring rear tires and marking the locations for precisely placing the mats before finishing the calibration with a couple of simple touches on the ADASLink® screen. “All set,” he says.

Roof repairs required removal of the camera on a 2021 Lexus UH, triggering a calibration. Fortunately, as Babcox Media’s Joe Keene demonstrates, this calibration is a simple and straightforward procedure with the ADASLink® diagnostic scan tool and the DAS 3000 static fixture. The key is patient precision with setting up and adjusting the targets, assisted by the built-in bubble levels. Following the test drive and post-scan, as well as thorough documentation for the customer, the job is complete. ADASLink®’s onscreen instruction ensures no steps are missed, eliminating guesswork and providing a thoroughly documented calibration for more than 25 million vehicles.

Windshield repair isn’t as simple as it used to be, since today new glass also requires new ADAS calibrations. Babcox Media’s Joe Keene demonstrates how such calibrations can be done accurately and efficiently on a front-facing camera with the Hunter ADASLink® diagnostic scan tool and the DAS 3000 static fixture. Wheel clamps and a target board are used to ensure the lane departure warning camera on VW and Audi vehicles is precisely and quickly calibrated, with special attention on suspension level control and correctly measuring the ride height. ADASLink®’s onscreen instruction ensures no steps are missed, eliminating guesswork and providing a thoroughly documented calibration for more than 25 million vehicles.

A collision repair required the removal of a side view mirror on this Nissan vehicle, requiring in turn the calibration of the Around View monitor system camera. Unlike many calibrations, this particular procedure included creating a floor grid. The number of measurements and the diligence necessary to perform them offered many opportunities for something to go wrong. However, as Babcox Media’s Joe Keene demonstrates, patiently following the step-by-step guidance provided by the ADASLink® diagnostic scan tool can make sure everything goes right.

Following a windshield replacement, Subaru requires that a static calibration be performed before the dynamic calibration on the vehicle’s “Eyesight,” or front-facing cameras. Babcox Media’s Joe Keene demonstrates that both types of calibration can be quickly and easily accomplished with the step-by-step onscreen guidance provided by Hunter Engineering’s ADASLink® premium scan tool and the DAS 3000 fixture.

Whether or not the blind spot sensor itself is damaged, if the rear fascia comes off, a calibration is called for. Using both the sophisticated electronics of Hunter’s ADASLink® diagnostic scan tool and old-school measurements with string and a plumb bob on a 2020 Mazda 6, Babcox Media’s Joe Keene demonstrates that the key to all ADAS calibrations is precision – and particularly so with blind spot sensors. ADASLink®’s onscreen instruction ensures that precision by eliminating guesswork and providing an accurately performed and thoroughly documented calibration for more than 25 million vehicles.
